Outboard | Transom Ht. | Remote Model | Tiller Included | iST- Electronic Shift & Throttle | Electric Start | Charging System | Prop Included | Power Thrust | Power Tilt & Trim | Gas Assist | Color |
---|---|---|---|---|---|---|---|---|---|---|---|
BF135 | 20" | X | X | 40A | X | Silver | |||||
BF135 | 20" | X | X | 40A | X | White | |||||
BF135 | 25" | X | X | 40A | X | Silver | |||||
BF135 | 25" | X | X | 40A | X | White | |||||
BF135 | 25" | X | X | 40A | X | Silver |
Reliable, Efficient 4-Stroke Design
World-renowned Honda quality combines proven reliability and superior fuel efficiency, with no oil mixing.
Legendary Quality Based on Honda Accord and CRV
By sharing many components with the Honda Accord, and CRV automobiles, the BF135 and BF150 gain years of proven Honda engineering and reliability.
VTEC® - Smooth acceleration and power (150hp)
Featured on the BF150, Honda’s Variable Valve Timing & Lift Electronic Control (VTEC®) system provides power where and when you need it. VTEC gives you a broader, flatter torque curve and smooth power delivery throughout the engine’s operating range. The result is a superior combination of power, torque and fuel economy. VTEC is the modern replacement for displacement.
Dual Stage Induction - Breathing easier improves performance
Honda’s unique variable intake system optimizes air flow to match the engine’s speed. The result? Maximized combustion efficiency, increased torque, and superb fuel economy.
Lean Burn Control® - Superior fuel efficiency
Lean Burn Control® increases fuel efficiency by allowing combustion to operate on a leaner air/fuel mixture. At cruising speed, this engine runs on up to 20% less fuel* than others in its class.
*Based on EPA Specific Fuel Consumption Mode.
Multi-port Programmed Fuel Injection (PGM-FI) - Powerful performance
Programmed Fuel Injection delivers the precise amount of fuel/air to each cylinder. The result is easy starts and instant throttle response with superior fuel efficiency.
Dual Overhead CAM (DOHC) - High horsepower, low maintenance
A powerful, compact 24-valve DOHC design creates more valve lift to pull in more air for increased horsepower. Low-maintenance design allows easy adjustment of the rocker arms. No multiple shims or trial-and-error adjusting needed.
NMEA 2000 - On-board connectivity
NMEA 2000 protocols allow engine data to be interfaced with on-board systems and systems displays, such as sonar or GPS.
True 5 Warranty
Honda's True 5 Warranty is the best in the business. This transferable, non-declining warranty is the same on the last day as it is on the first.
Superior Battery Charging - More usable power
Honda's proven "on demand" 51 amp belt-driven alternator reduces heat buildup and provides superior battery charging capability - 30 amps at 1000 RPM and 40+ amps above 2000 RPM.
Engine Alert System - Keeps you informed
The ECM monitors vital engine functions and prevents engine damage by alerting the operator of:
- Overheating
- Water in Fuel
- Low Oil PSI
- Battery
- Over-Rev
- Critical Engine Function
Fisherman Friendly Variable Speed Trolling
The BF135 and BF150 offer optional push-button variable speed trolling control. Simply push the toggle switch to adjust the trolling speed in 50 RPM increments from 650 RPM to 1000 RPM.
4-Front Corrosion Protection System - Fights the elements
A patented, "Double Sealed" multi-layered paint process. Sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.
Engine Command Module - Optimum performance
The ECM receives constant input from 18 different sensors to deliver instant starts, smooth operation, strong performance and excellent fuel efficiency.
LAF & Knock Sensors - Optimum Efficiency
Linear Air Fuel (LAF) and knock sensors help determine correct fuel flow and ignition curve to maximize performance and fuel efficiency.
Counter Rotation Available
Counter rotating models are available for multiple engine applications. These models improve efficiency, hull maneuverability and decreases driver fatigue.
3-Way Cooling System - Cool running durability
Three separate cooling systems keep the cylinder heads running cooler for long-term durability.
Positive Lubrication - better durability
A crankshaft-driven, automotive-style trochoid oil pump ensures long-term durability of critical engine components.
Convenient Single Latch Cowl
A single front-mounted latch combines with 4 securing points to ensure a water-tight seal.
Sealed Starter - Protection for long life
The starter motor is inverted into a sealed chamber that protects the starter drive from the elements.
Fresh Water Flushport
Flushes debris and saltwater out of the engine, extending the life of the outboard.
Stainless Steel components (Steering Arm, Tilt Tube and all Shafts) - corrosion resistance
Stainless steel components provide durability with long-term corrosion resistance.
Ultra Low 3 Star CARB Emissions
Environmentally conscious technology. All Honda Marine engines exceed the highest CARB 3-Star rating to meet the rigorous California Air Resource Board's standards.
Built-In Pitot Tube
Built-in pitot tube in the gear case eliminates the need to drill holes in your boat for installation.
Available in 20 and 25 inch shaft lengths
Engine |
|
Type | 4-Stroke DOHC 4 Cylinder/16 Valves |
Displacement | 2,354 cc (144 cubic inches) |
Bore & Stroke | 87 mm x 99 mm (3.4 x 3.9 inches) |
Full Throttle RPM Range | 5,000-6,000 RPM |
Rated Power | 135 HP @ 5,500 RPM |
Cooling System | Water Cooled |
Fuel Delivery | Programmed Fuel Injection |
Ignition System | MicroComputer Programmed |
Starting System | Electric |
Exhaust | Through Hub |
Lubrication | Wet Sump |
Trim Range | -4° to +16° |
Tilt Range | 72° |
Drive |
|
Gear Ratio | 2.14:1 |
Gear Shift | F-N-R |
Equipment |
|
Alternator (Electric Start) | 51 Amp |
Battery Charging Power | 30 Amp (1000 RPM), 40 Amp (2000+ RPM) |
Propeller | Optional |
Power Tilt | NA |
Power Trim & Tilt | Standard |
Gas Assisted Tilt | NA |
Oil Pressure Alert | Standard |
Temperature Alert | Standard |
Rev-Limiter | Standard |
Speedometer Pickup | Standard |
Dimensions |
|
Overall Width | 580 mm/22.8 inches |
Transom Height |
|
L Type | 508 mm/20 inches |
X Type | 635 mm/25 inches |
Dry Weight |
|
L-Type | 217 kg/478 lbs. |
X-Type | 220 kg/485 lbs. |
Spec |
|
Transom Ht. | 25" |
Remote Model | X |
Tiller Included | |
iST- Electronic Shift & Throttle | |
Electric Start | X |
Charging System | 40A |
Prop Included | |
Power Thrust | |
Power Tilt & Trim | X |
Gas Assist | |
Color | White |
