|Outboard||Transom Ht.||Remote Model||Tiller Included||iST- Electronic Shift & Throttle||Electric Start||Charging System||Prop Included||Power Thrust||Power Tilt & Trim||Gas Assist|
Proven 4-stroke design
World-renowned Honda quality combines proven reliability and superior fuel efficiency, with no oil mixing.
Legendary Honda Reliability
The technology we applied to our 75, 90, and 100hp outboard engine is the very same that powers one of the most popular cars in the world, the Honda Fit.
True 5 Warranty
Honda's True 5 Warranty is the best in the business. This transferable, non-declining warranty is the same on the last day as it is on the first.
VTEC® - Smooth acceleration and power (90hp)
Available on the BF90 and BF100, Honda’s Variable Valve Timing & Lift Electronic Control (VTEC®) system provides power where and when you need it. VTEC gives you a broader, flatter torque curve and smooth power delivery throughout the engine’s operating range. The result is a superior combination of power, torque and fuel economy. VTEC is the modern replacement for displacement.
Programmed Fuel Injection - Powerful performance
Programmed Fuel Injection delivers the precise amount of fuel/air to each cylinder. The result is easy starts and instant throttle response with superior fuel efficiency.
Lean Burn Control® - Superior fuel efficiency
Lean Burn Control® increases fuel efficiency by allowing combustion to operate on a leaner air/fuel mixture. At cruising speed, the BF75, 90 and 100 run on up to 20% less fuel* than others in its class.
*Based on EPA Specific Fuel Consumption Mode.
BLAST® System - improves acceleration at low speeds
Boosted Low Speed Torque, or BLAST, improves acceleration at low speeds. A quick movement of the throttle control activates the BLAST® system, advancing the ignition curve aggressively. "Hole Shot" is vastly improved as more horsepower gets the hull up on plane quicker.
Meets NMEA 2000 standards - on-board connectivity
NMEA 2000 protocols allow engine data to be interfaced with on-board systems and systems displays, such as sonar or GPS.
Fisherman Friendly Variable Speed Trolling
Another great advantage for fishermen is the 75, 90, and 100’s push button troll speed. Simply push up or down in 50 RPM increments from 750rpm to 1000 rpm. It’s standard on the tiller and optional on the remote.
Engine Alert System - Keeps you informed
The Engine Alert System uses visual, audio and RPM reduction circuits to alert the operator of over-heating, low oil PSI and over-revving, preventing engine damage.
4-Front Corrosion Protection System - Fights the elements
The Corrosion Protection System is a patented "Double Sealed" multi-layered paint process. Sacrificial anodes and stainless steel technology, along with waterproof connectors, all enhance corrosion protection.
High Performance Gearcase - gets you going faster
Designed to get you going faster, the high performance gearcase reduces drag, greatly reduces hull porpoise and minimizes spray, thus increasing acceleration and top speed.
A longer anti-ventilation plate helps trap water flowing to the propeller to minimize porpoising, while a streamlined front and longer bullet reduce drag for enhanced acceleration and fuel efficiency. A front splash plate reduces spray from the hull bottom, maintaining a dry deck above, and a 2.33:1 gear ratio affords the use of 13- to 14-inch diameter propellers for heavier loads.
Superior Battery Charging - More usable power
There's always plenty of electric power with Honda's exclusive neodymium magnet flywheel. The alternator develops 44 amps in total and 35 amps of charging amps, it's twice the output of some competitors. It provides high output and keeps battery banks charged all day, even when running multiple accessories.
Center Mount Tiller - Easier control
The ergonomically designed tiller handle is longer for improved handling. Adjustments for throttle and steering friction allow easier control. Up front shift lever, PTT switch, and engine alert lamps provide added convenience.
The BF75, BF90, and BF100 are among the lightest engines in their class.
Ultra Low 3 Star CARB Emissions
Environmentally conscious technology. All Honda Marine engines exceed the highest CARB 3-Star rating to meet the rigorous California Air Resource Board's standards.
An easy "screw-type" valve adjuster system requires no shims, which reduces maintenance costs. Front-mounted oil filter and oil filler make for easy maintenance.
Torsion Dampener - improved handling.
Sometimes called a flywheel, it is located near the base of the powerhead. This design lowers the center of gravity for improved handling.
SOHC 4 Valve/Cyl. Design - max power
The powerful 1.5L, 4-cylinder design utilizes a single overhead cam, and two intake valves to deliver maximum torque and power.
3-Way Cooling System - Cool running durability
Three separate cooling systems keep the cylinder heads running cooler for long-term durability.
Top Mounted Electronics
The alternators, ignition and other critical electrical components are mounted near the top of the powerhead to stay cool and dry. The result? Dependable performance.
Fresh Water Flushport
Flushes debris and saltwater out of the engine, extending the life of the outboard.
3 Position Tiller Handle
The 3 Position Tiller Handle adjusts to your comfort for easiest hull maneuverability.
Built-In Pitot Tube
Built-in pitot tube in the gear case eliminates the need to drill holes in your boat for installation.
Non-Linear Mounting System - Smoother operation
Patented non-linear rubber mounts provide smoother operation at all engine speeds.
Sealed Starter - Protection for long life
The starter motor is inverted into a sealed chamber that protects the starter drive from the elements.
A crankshaft-driven, automotive-style trochoid oil pump ensures long-term durability of critical engine components.
Available in 20 and 25 inch shaft configurations
|Type||4-Stroke SOHC 4 Cylinder/16 Valves|
|Displacement||1,496 cc (91.4 cubic inches)|
|Bore & Stroke||73 mm x 89.4 mm (3.0 x 3.5 inches)|
|Full Throttle RPM Range||5,500-6,300 RPM|
|Rated Power||100 HP @ 5,900 RPM|
|Cooling System||Water Cooled|
|Fuel||Unleaded Gas (91 Octane)|
|Fuel Delivery||Programmed Fuel Injection|
|Ignition System||MicroComputer Programmed|
|Trim Range||-4° to +16°|
|Alternator (Electric Start)||44 Amp|
|Battery Charging Power||35 Amp|
|Power Trim & Tilt||Standard|
|Gas Assisted Tilt||NA|
|Oil Pressure Alert||Standard|
|Overall Width||480 mm/18.9 inches|
|L Type||508 mm/20 inches|
|X Type||635 mm/25 inches|
|L-Type||163 kg/359 lbs.|
|X-Type||166 kg/365 lbs.|
|iST- Electronic Shift & Throttle|
|Power Tilt & Trim||X|
